Plattform: UltraSlim_14SXP_UHP|UHD
- Ultra Slim Batterie: starting at 71mm
- Ultra High Power: up to 10kW
- Ultra High Density:
- Gravimetric: around 200Wh/kg
- Volumetric: around 200Wh/l
- Active or passive cooling
- Highly adjustable capacity: 1,1kWh to 3,9kWh
- Highly adjustable plugs, connectors, handles, displays etc.
- Up to 200A continuous discharge and charge current.
- Balancing
- CAN-Communication, Bluetooth
- Possible Voltage levels: 12V, 24V, 48V, 72V, 98V
- NMC
UltraSlim_14SXP_UHP | UHD
Varianten
Plattform: Blocks_14SXP
- Highly adjustable capacity: 3 kWh to 12 kWh
- High Power: up to
- Discharge: 13kW cont | 30kW peak
- Charge: 10kW cont. | 30kW peak
- High Density:
- Gravimetric: around 170Wh/kg
- Volumetric: around 200Wh/l
- Highly adjustable plugs, connectors, handles, displays etc.
- High currents: up to
- Discharge: 128A cont. | 600A peak
- Charge: 192A cont. | 600A peak
- Balancing, Bluetooth
- CAN-Communication
- Possible Voltage levels: 24V, 48V, 72V, 98V
- NMC, LFP
Blocks_14SXP
Varianten
